EJMM3309T BALDOR 5HP 3PH SUPER-E PUMP MOTOR 37F696S521G2

Electric Motors

Three Phase Electric Motors

Baldor Motors Three Phase

Baldor Three Phase Pump Motors

Baldor Three Phase ODP Close-Coupled Pump Motors

5HP BALDOR 1160RPM 215JM OPSB 3PH SUPER-E PUMP MOTOR EJMM3309T

Picture is for reference only.

Part Number:

EJMM3309T

Model/Spec Number:

37F696S521G2

Manufacturer:

ABB/Baldor

EJMM3309T BALDOR 5HP Three Phase Close-Coupled Pump Electric Motor is for operations where continuous or frequent duty is required. Usable for a wide variety of applications for circulating and transferring fluids. Mounting designed to support pump unit. Super-E motors are designed to conserve energy over extended time periods.

MSRP: $2,939.00

Regular Price

USD

2,331

QTY

Shipping Details

Free No Rush Shipping

Weight:

141 lbs

Dimensions:

20 x 27 x 18 inches

HS Code:

8501524000

UPC:

781568809495

Technical Details

Specifications

Brand:	Baldor
Application:	Closed Coupled
Output HP:	5
Output KW:	3.7
Output RPM:	1160
Frame Size NEMA:	215JM
Mount NEMA:	C Face With Base
Enclosure NEMA:	OPSB
Enclosure IEC:	IP23
Voltage:	230/460//190/380

Documentation

EJMM3309T-InfoPacket

Additional Information

APPLICATIONS: Designed for operations where continuous or frequent duty is required. Usable for a wide variety of applications for circulating and transferring fluids. Mounting designed to support pump unit. Super-E motors are designed to conserve energy over extended time periods. FEATURES: Super-E Premium Efficient Motor Heavy gauge steel frames Moisture resistant ISR® (Inverter Spike Resistant) copper windings Over-sized ball bearings with locked drive end construction to minimize endplay Low-loss electrical grade lamination steel Three year warranty
