5HP BALDOR 1750RPM 184TC TEFC 3PH SUPER-E EPOXY WASHDOWN BRAKE MOTOR CEWDBM3615T

Part Number:

CEWDBM3615T

Model/Spec Number:

36G566S268G1

Manufacturer:

ABB/Baldor

CEWDBM3615T BALDOR 5HP SUPER-E EPOXY WASHDOWN BRAKE ELECTRIC MOTOR is designed for use with food processing and other applications that regularly expose the motor to high pressure washdown.

MSRP: $6,167.00

Regular Price

USD

$

4,432

02

QTY

Login to View Discounts

Shipping Details

Free No Rush Shipping

Weight:

110 lbs

Dimensions:

16 x 36 x 23 inches

HS Code:

8501.52.4000

UPC:

781568392904

Technical Details

Specifications

Brand:	Baldor
Application:	Washdown Epoxy
Output HP:	5
Output KW:	3.7
Output RPM:	1750
Frame Size NEMA:	184TC
Mount NEMA:	C Face With Base
Enclosure NEMA:	TEFC
Enclosure IEC:	IP55
Voltage:	230/460

Documentation

CEWDBM3615T-InfoPacket (1)

Additional Information

APPLICATIONS: Designed for use with food processing and other applications that regularly expose the motor to high pressure washdown.

FEATURES:

Class F insulated motor with 1.15 Service factor or higher that operates within class "B" temperature limits at rated horsepower
Standard NEMA BA dimension 300 series stainless steel hardware
Moisture sealant on bolt heads, between frame and end plates
Neoprone gaskets
Spring-set brake internally connected to the motor
Power off manual release
Resets automatically
NEMA Premium® Efficiency and inverter-ready
230/460V brakes are connected in conduit box
