Electric Motors

/

Three Phase Electric Motors

/

Baldor Motors Three Phase

/

Baldor Three Phase Brake Motors

/

Baldor Three Phase Epoxy Washdown Brake motors

/

2HP BALDOR 1760RPM 145TC TEFC 3PH SUPER-E EPOXY WASHDOWN BRAKE MOTOR CEWDBM3558T

Picture is for reference only.

Part Number:

CEWDBM3558T

Model/Spec Number:

35MM610G073G1

Manufacturer:

ABB/Baldor

CEWDBM3558T BALDOR 2HP SUPER-E EPOXY WASHDOWN BRAKE ELECTRIC MOTOR is designed for use with food processing and other applications that regularly expose the motor to high pressure washdown.

MSRP: $4,219.00

Regular Price

USD

$

3,032

05

QTY

Login to View Discounts

Shipping Details

Free No Rush Shipping

Weight:

60 lbs

Dimensions:

13 x 31 x 19 inches

HS Code:

8501.52.4000

UPC:

781568392881

Technical Details

Specifications

Brand:	Baldor
Application:	Washdown Epoxy
Output HP:	2
Output KW:	1.5
Output RPM:	1760
Frame Size NEMA:	145TC
Mount NEMA:	C Face With Base
Enclosure NEMA:	TEFC
Enclosure IEC:	IP55
Voltage:	230/460

Documentation

CEWDBM3558T-InfoPacket (1)

Obsolete-35MM610N909G1

Additional Information

APPLICATIONS: Designed for use with food processing and other applications that regularly expose the motor to high pressure washdown.

FEATURES:

Class F insulated motor with 1.15 Service factor or higher that operates within class "B" temperature limits at rated horsepower
Standard NEMA BA dimension 300 series stainless steel hardware
Moisture sealant on bolt heads, between frame and end plates
Neoprone gaskets
Spring-set brake internally connected to the motor
Power off manual release
Resets automatically
NEMA Premium® Efficiency and inverter-ready
230/460V brakes are connected in conduit box
