1HP BALDOR 1750RPM 56C XPFC 90VDC EXPLOSION PROOF MOTOR CDPX3545

Product Overview

CDPX3545 BALDOR 1HP NEMA Permanent Magnet DC Explosion Proof Motor. Thermostat and explosion proof conduit box included. Not Tach adaptable.

Part Number:

CDPX3545

Model/Spec Number:

35P565Z235G1

Manufacturer:

ABB/Baldor

Manufacturer Part Number:

CDPX3545

Technical Details

Specifications

Application	Explosion Proof
Output HP	1
Output KW	0.75
Output RPM	1750
Frame NEMA	56C
Mount NEMA	C-Face With Base

Documentation

CDPX3545-InfoPacket

Explosion Proof Definitions

Additional Information

BALDOR NEMA Frame Explosion Proof DC motors include permanent magnet design for adjustable speed operation from SCR controls and have a 20:1 constant torque speed range. Division 1, Class I, Group D and Class II, Group F & G, T3C. locations with listing by both UL and CSA. Thermostat and explosion proof conduit box included. Not Tach adaptable.

APPLICATIONS: Includes conveyors, feeders, mixers and pumps (adjustable speed and constant torque for hazardous locations).

NOT Tach adaptable
5/8" shaft diameter
Class F insulation
Class I, Group D; Class II, Group F&G
UL and CSA recognized

Note: Explosion-proof motors have a tight fit between mating parts to ensure the integrity of the explosion-proof enclosure. This can lead to an accumulation of moisture inside the motors due to condensation. Care should be used when selecting an explosion-proof motor, especially when installed outdoors and on intermittent duty.
