1.5HP BALDOR 1770RPM 56C TENV 3PH D-SERIES SUPER-E BRAKE MOTOR VEBNM3554-D

Picture is for reference only.

Part Number:

VEBNM3554-D

Model/Spec Number:

35X058G178G1

Manufacturer:

ABB/Baldor

VEBNM3554-D BALDOR 1.5HP D-Series Brake Motor is designed for use with unit and baggage handling, conveyors, packaging equipment, machine tools, hoists, elevators and door operators.

MSRP: $2,562.00

Regular Price

USD

1,841

QTY

Shipping Details

Free No Rush Shipping

Weight:

62 lbs

Dimensions:

10 x 26 x 15 inches

HS Code:

8501.52.4000

UPC:

781568810521

Technical Details

Specifications

Brand:	Baldor
Application:	Brakemotor
Output HP:	1.5
Output KW:	1.1
Output RPM:	1770
Frame Size NEMA:	56C
Mount NEMA:	C Face No Base
Enclosure NEMA:	TENV
Enclosure IEC:	IP44
Voltage:	230/460

Documentation

VEBNM3554-D-InfoPacket

Additional Information

APPLICATIONS: Designed for use with unit and baggage handling, conveyors, packaging equipment, machine tools, hoists, elevators and door operators.

FEATURES:

UL/CSA recognized and CE certified
Dodge “D” Series brakes are spring set
Brakes are single phase with built-in rectifier to DC
Brakes have a manual release lever
56-140 frames have low profile F3 top-mounted conduit box
D series brake motors can be universally mounted
143-145TY and 143-145TYC frame motors have a special base with 56, 143 and 145 slots used on OEM conveyors
