IDDRPM363504R2 BALDOR 350HP RPM AC Inverter Duty Motor R36-A000-0265

Electric Motors

Three Phase Electric Motors

Baldor Motors Three Phase

Baldor Three Phase RPM AC Inverter Duty Motors

350HP BALDOR 1777RPM RL3614Z 460V DPFV 3PH RPM AC Inverter Duty Motor IDDRPM363504R2

Picture is for reference only.

Part Number:

IDDRPM363504R2

Model/Spec Number:

R36-A000-0265

Manufacturer:

ABB/Baldor

IDDRPM363504R2 BALDOR 350HP RPM AC Inverter Duty Motors are designed for extruders, conveyors, crane & hoist systems, converting, pumps, web processing, test stands, traction duty, winders, and printing.

MSRP: $63,877.00

Regular Price

USD

52,208

QTY

Shipping Details

Free No Rush Shipping

Weight:

2,000 lbs

Dimensions:

36 x 61 x 38 inches

HS Code:

8501.53.8040

UPC:

781568580509

Technical Details

Specifications

Brand:	Baldor
Application:	Inverter Duty
Output HP:	350
Output KW:	261
Output RPM:	1777-2960
Frame Size NEMA:	RL3614Z
Mount NEMA:	With Base
Enclosure NEMA:	DPFV
Enclosure IEC:	IP23
Voltage:	460

Documentation

IDDRPM363504R2-InfoPacket

Additional Information

Baldor Three Phase RPM AC Inverter Duty Motors are designed for extruders, conveyors, crane & hoist systems, converting, pumps, web processing, test stands, traction duty, winders, and printing.

FEATURES:

Compact square laminated steel frame FL210-L440 (FL180 is extruded aluminum) for inverter duty and vector duty 1000:1 constant torque.
Premium class H insulation, 40 C ambient, 1.0 S.F. Ball bearing.
Three normally closed thermostats (one per phase).
Surpasses the requirements of MG1, Part 31. VPI insulation & insulated O.D.E. bearing is standard on all L440 frames.
Exclusive optimum pole Inverter Duty - not for across the line operation.
