IDDRPM322006R1 BALDOR 200HP RPM AC Inverter Duty Motor R32-A000-0010

Electric Motors

Three Phase Electric Motors

Baldor Motors Three Phase

Baldor Three Phase RPM AC Inverter Duty Motors

200HP BALDOR 1170RPM RL3213Z 460V DPFV 3PH RPM AC Inverter Duty Motor IDDRPM322006R1

Picture is for reference only.

Part Number:

IDDRPM322006R1

Model/Spec Number:

R32-A000-0010

Manufacturer:

ABB/Baldor

IDDRPM322006R1 BALDOR 200HP RPM AC Inverter Duty Motors are designed for extruders, conveyors, crane & hoist systems, converting, pumps, web processing, test stands, traction duty, winders, and printing.

MSRP: $50,443.00

Regular Price

USD

41,228

QTY

Shipping Details

Free No Rush Shipping

Weight:

1,357 lbs

Dimensions:

33 x 61 x 34 inches

HS Code:

8501.53.4000

UPC:

781568803745

Technical Details

Specifications

Brand:	Baldor
Application:	Inverter Duty
Output HP:	200
Output KW:	150.0
Output RPM:	1170-2000
Frame Size NEMA:	RL3213Z
Mount NEMA:	With Base
Enclosure NEMA:	DPFV
Voltage:	460
Frequency (Hz):	40-68.4

Documentation

IDDRPM322006R1-InfoPacket

Additional Information

Baldor Three Phase RPM AC Inverter Duty Motors are designed for extruders, conveyors, crane & hoist systems, converting, pumps, web processing, test stands, traction duty, winders, and printing.

FEATURES:

Compact square laminated steel frame FL210-L440 (FL180 is extruded aluminum) for inverter duty and vector duty 1000:1 constant torque.
Premium class H insulation, 40 C ambient, 1.0 S.F. Ball bearing.
Three normally closed thermostats (one per phase).
Surpasses the requirements of MG1, Part 31. VPI insulation & insulated O.D.E. bearing is standard on all L440 frames.
Exclusive optimum pole Inverter Duty - not for across the line operation.
