5HP BALDOR 1750RPM 1810ATC TEFC 180VDC PERMANENT MAGNET MOTOR W/TACH CDPT3605
5HP BALDOR 1750RPM 1810ATC TEFC 180VDC PERMANENT MAGNET MOTOR W/TACH CDPT3605
Part Number:
CDPT3605Model/Spec Number:
36P333Z509Manufacturer:
ABB/BaldorTechnical Details
Specifications
Application: | General Purpose |
Output HP: | 5 |
Output KW: | 3.7 |
Output RPM: | 1750 |
Frame NEMA: | 1810ATC |
Mount NEMA: | C-Face With Base |
Input Voltage DC: | 180 |
Full Load Amps: | 24.5 |
Winding: | Permanent Magnet |
Enclosure NEMA: | TEFC |
Documentation
Additional Information
BALDOR NEMA frame DC motors include permanent magnet design for adjustable speed operation from SCR controls and have a 20:1 constant torque speed range with NEMA Type K control.
APPLICATIONS: include conveyors, extruders, winders, printing presses and metering pumps. Most designs are constructed so a tachometer may be added for closed loop applications.
- Precise speed regulation
- 1 1/8" Keyed output shaft
- Provides an integral 50 VDC per 1000 RPM precision tachometer for closed loop drive system
- Class F insulation
- Double sealed ball bearings
- UL and CSA recognized
