1/4HP MARATHON 1075RPM 48Y 115V OPAO 1PH MOTOR X034

Catalog Number:  X034
Model Number:  48A11O1773
Description:  1/4HP,1075RPM,48Y,115V,OPAO,1PH,60HZ
Design: PERMANENT SPLIT CAPACITOR, FOUR-SPEED
Ship Weight:  14 lbs.

This Marathon motor is Non-Returnable.

Please take the time to identify your motor needs. It is the customer’s responsibility to review all product information provided to determine the correct mechanical and electrical characteristics needed for your application. If you need further assistance with this product to identify your product specifications, please contact our customer service department to answer any questions you may have.

APPLICATIONS: Designed to replace PSC and Shaded pole motors, used in direct drive furnace, air conditioners, and other blowers.

PERMANENT SPLIT CAPACITOR: Operates similarly to capacitor-start motors, but there is no centrifugal starting switch and what correspond to the "start" windings (second windings) are permanently connected to the power source (through a run capacitor), along with the run windings. PSC motors are frequently used in air handlers, blowers, and fans (including ceiling fans) and other cases where variable speeds are desired.

FEATURES:

  • Capacitor not included
  • Automatic reset thermal protector
  • Multi-speed capacity
  • Torsion Flex Mount
  • Open frame and bracket
  • Three lug mount fits 9” or 10” bolt circle Mounting holes on lugs are .435” dia., with grommets and sleeves for .26” dia. option
  • Weather resistant reversing plug
  • 30” long leads
  • Ball Bearings
  • UL Recognized and CSA Certified

Phase

1

Insulation Class

B

Frame

48Y

Duty

CONTINUOUSAOM

Enclosure

OPAO

Ambient

40

Mounting

Three Lug Mount

NEMA Design

NO DESIGN CODE

Orientation

HORIZONTAL

Starting Type

PSC 4 SPEED

Assembly

F1 ONLY

KVA Code

A

Drive End Bearing

BALL

IP Code

10

Opposite End Bearing

BALL



Drive End Bearing Size

6203

Rotation

SELECTIVE CCW

Opposite End Bearing Size

6203



Weight

14 LB lbs



CE

N

CSA

Y

UL

Recognized Construction and Protector

Thermal Protection

Automatic Protector (under locked rotor only)

1/4HP MARATHON 1075RPM 48Y 115V OPAO 1PH MOTOR X034
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: X034
Stock # X034
Price: $90.00
Compare At: $160.00
