3/4HP MARATHON 1140RPM 143T 115/208-230V TEFC 1PH MOTOR I707

Catalog Number:  I707
Model Number:  143TBFR5376
Description:  3/4HP,1140RPM,143T,115/208-230V,TEFC,1PH,60HZ
Design: CAPACITOR START
Ship Weight:  42 lbs.

This Marathon motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales office for particulars.

APPLICATIONS: General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use.

FEATURES:

  • No overload protection
  • Capacitor Start/Capacitor Run design for reduced amperage
  • Ball bearings
  • Will accept C-Face kit
  • Heavy gauge steel construction
  • 1.15 Service Factor
  • UL Recognized and CSA Certified
  • Footnotes: 1,14,18

Phase 1 Insulation Class B
Frame 143T Duty CONTINUOUS
Enclosure TEFC Ambient 40
Mounting Rigid NEMA Design L
Orientation HORIZONTAL Starting Type CAP START CAP RUN
Assembly F1 ONLY KVA Code L
Drive End Bearing BALL IP Code 43
Opposite End Bearing BALL
Drive End Bearing Size 6205 Rotation SELECTIVE CCW
Opposite End Bearing Size 6203
Weight 42 LB lbs
CE N CSA Y
UL Recognized Construction
Thermal Protection
3/4HP MARATHON 1140RPM 143T 115/208-230V TEFC 1PH MOTOR I707
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: I707
Stock # I707
