1/6HP MARATHON 1725RPM 48 115V TEFC 1PH MOTOR H116
|Ship Weight:||15 lbs.|
APPLICATIONS: General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use.
SPLIT-PHASE: A single-phase motor that consists of a running winding, starting winding, and centrifugal switch. The reactance difference in the windings creates separate phases, which produce the rotating magnetic field that starts the rotor.
- No overload protection
- Economical split phase design
- Ball bearings
- Heavy gauge steel construction
- 1.0 Service Factor
- UL Recognized and CSA Certified
- Footnotes: 3,17
|Orientation||Horizontal or Vertical||Starting Type||Switch and Mech|
|Drive End Bearing||BALL||IP Code||N/A|
|Opposite End Bearing||BALL|
|Drive End Bearing Size||6203||Rotation||Select Counter clockwise|
|Opposite End Bearing Size||6203||Hazardous Location||N/R|
|Weight||15 LB lbs|
