1/2HP LEESON 1725RPM 56 DP 1PH MOTOR M900599.00

Catalog Number:  M900599.00 - FREE Ground Shipping in USA
Model Number:  56S17D5710A
Description:  1/2HP,1725RPM,56,DP,1PH,60HZ,SPLIT PHASE
Ship Weight:  30 lbs.

This Leeson motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

LEESON Split Phase Belted Fan Motor is designed for use in residential and commercial fans and blowers where low starting torque is required. Ideal for use with air conditioners, roof ventilators and exhaust fans.

FEATURES:

  • Durable rolled steel frame
  • Standard 56-frame resilient base
  • 5/8" Keyed output shaft
  • Automatic overload protection
  • 1.25 Service factor
  • UL Recognized and CSA Certified
  • Non USA manufactured, MX



Volts 115 Volts   Volts 115
F.L. Amps 8.4 F.L. Amps   F.L. Amps 4.5
S. F Amps 9.1 S. F Amps   S. F Amps 5.1
RPM 1800 Hertz 60/60
HP 1/2 Duty CONTINUOUS TYPE SS
KW 0.37 Model # 56S17D5710A
Frame 56 Serv. Factor 1.25 Phase 1
Max Amb 40 Design 2VT Code M
Insul Class B Protection AUTOMATIC Therm.Prot.
Eff 100%   Eff 75%   PF
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 203
CC Number   CE No Bearing PE 203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 30 LB Enclosure DP Lubrication STANDARD
Nameplate   Mounting RESILIENT BASE-EXTENDED STUDS Rotation SELECTIVE CCW
1/2HP LEESON 1725RPM 56 DP 1PH MOTOR M900599.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: M900599.00
Stock # M900599
Price: $304.00
Compare At: $767.00
