5HP LEESON 1760RPM 184T TEAO 3PH MOTOR 824529

Catalog Number:  824529.00
Model Number:  184TTTN16542
Description:  5HP,1760RPM,184T,TEAO,3PH,COOLING TOWER
Ship Weight:  155 lbs.

This LEESON Motor Can Ship Ground Only.
For expedited needs please contact our sales team.

Applications: Cooling towers, Fan and Blowers, and other severe duty environments where long life and high efficiency are desired.

Premium Features:

  • Made in the USA
  • Two year warranty
  • Epoxy painted
  • Designed for shaft up mounting
  • Shaft grounding ring (SGRs) installed
  • 10 : 1 constant and variable torque rated
  • Complete cast iron construction for rigidity and reduced vibration
  • Inpro Shaft seal protected
  • Class F insulation
  • F-1 / F-2 Capable
  • Inverter rated IRIS™ insulation system
  • Extra nameplate with CE for external mounting
  • Brass T-drain installed - both ends at 6:00
  • Re-greaseable bearings
  • Severe duty treatment of internal parts
  • 1.15 S.F. under sine wave power
Volts 230 Volts 460 Volts
F.L. Amps 12.4 F.L. Amps 6.2 F.L. Amps
S. F Amps 14.4 S. F Amps 7.2 S. F Amps
RPM 1800 Hertz 60
HP 5 Duty LEESON AIR OVER TYPE TV
KW 3.7
Frame 184T Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code J
Insul Class F Protection NOT Therm.Prot.
Eff 100% 90.2 Eff 75%   PF 83.5
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6206
CC Number EXEMPT CE No Bearing PE 6206
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 155 LB Enclosure TEAO Lubrication STANDARD
Nameplate B-92720-BM-ACDLM-HJK-A-X-D Mounting RIGID Rotation REV
Assembly   Shaft Dia. 1.1250 IN Ext. Diag. A-EE7308-LE
5HP LEESON 1760RPM 184T TEAO 3PH MOTOR 824529
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 824529.00
Stock # 824529
Price: $748.00
Compare At: $1,887.00
