2HP LEESON 1740RPM 145TC TEFC 1PH WG MOTOR 121633.00

Catalog Number: 121633.00 - FREE Ground Shipping in USA
Model Number: CZ145K17WC1
Description:  2HP,1740RPM,145TC,TEFC,1PH,60HZ,SST WASHGUARD
Ship Weight: 57 lbs.

This Leeson motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

LEESON WASHGUARD Premium Duck All-Stainless Motor is designed specifically to meet the demanding sanitation requirements of the pharmaceutical, food processing and beverage industries. This motor is also ideal in clean room and severe chemical-processing applications involving frequent washdown with nitric acid and caustic lye.

FEATURES:

  • Made in USA
  • Durable 300-Series stainless steel exterior components- frame, endshields, shaft extension, fan guard, hardware, conduit box and cover
  • C-Face mounting provisions less base
  • 5/8" Keyed output shaft
  • Capacitor Start/Capacitor Run
  • Solid State Sinpac® switch – no mechanical switch contacts to corrode and fail
  • Double sealed bearings with moisture resistant high temperature grease
  • Interior coatings applied to the rotor and stator protect against corrosion
  • Viton sealing components for superior chemical resistance
  • Removable hydrophobic breathers in opposite shaft end bell and conduit box equalize pressure without allowing moisture to enter
  • LEESON’s exclusive IRIS® Inverter-Rated Insulation System provides extra protection and long life, especially in inverter-driven applications
Volts 115 Volts 208-230 Volts
F.L. Amps 20 F.L. Amps 10.2-10 F.L. Amps
S. F Amps 22 S. F Amps 11.2-11 S. F Amps
RPM 1800 Hertz 60
HP 2 Duty CONTINUOUS TYPE KF
KW 1.49 Model # CZ145K17WC1B
Frame 145TC Serv. Factor 1.15 Phase 1
Max Amb 40 Design L Code J
Insul Class F Protection NOT Therm.Prot.
Eff 100% 80 Eff 75%   PF 80
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number None CE No Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 57 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 081120 Mounting ROUND Rotation SELECTIVE CCW
Assembly 042539 Shaft Dia. 7/8 IN Ext. Diag. 005314.03
2HP LEESON 1740RPM 145TC TEFC 1PH WG MOTOR 121633.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 121633.00
Stock # 121633
Price: $890.00
Compare At: $2,243.00
