1HP LEESON 1725RPM 56C DP 1PH MOTOR 110036.00

Catalog Number:  110036.00 Made in USA
Model Number:  M6C17DC1K
Description:  1HP,1725RPM,56C,DP,1PH,60HZ
Ship Weight:  30 lbs.

APPLICATIONS: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

FEATURES:

  • Made in USA
  • Durable rolled steel frame
  • 5/8" shaft output diameter
  • Manual overload protection
  • High-quality ball bearings
  • Capacitor Start
  • Easy-to-read nameplate
  • UL Recognized Component Listing and CSA approval.
  • 1 year warranty
Volts 115 Volts 208-230 Volts
F.L. Amps 12.8 F.L. Amps 6.4 F.L. Amps
S. F Amps 13.6 S. F Amps 6.8 S. F Amps
RPM 1800 Hertz 60
HP 1 Duty CONTINUOUS TYPE CD
KW .75 Model # M6C17DC1K
Frame E56 C Serv. Factor 1.15 Phase 1
Max Amb 40 Design N Code K
Insul Class B Protection MANUAL Therm.Prot. CEJ50CA
Eff 100% 75 Eff 75%   PF 68
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE No Bearing PE 6203
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 30 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004004 Mounting C FACE Rotation SELECTIVE CCW
1HP LEESON 1725RPM 56C DP 1PH MOTOR 110036.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 110036.00
Stock # 110036
Price: $260.00
Compare At: $632.00
