1/3HP LEESON 1800RPM 56C ODP 115/230V 1PH ECOSAVER MOTOR E100024.00

Catalog Number:  E100024.00 - FREE Ground Shipping in USA
Model Number:  C4K17DC12A
Description:  1/3HP,1725RPM,56C,DP,115/230V,1PH,60HZ,ECOSAVER
Ship Weight:  19 lbs.

LEESON Single Phase ECOSAVER Motors satisfies the mandated efficiencies of NEMA Premium and carries a three year warranty. For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans and other standard industrial applications.


  • Durable rolled steel construction
  • Continuous duty
  • 5/8" Keyed output shaft
  • Double shielded ball bearings
  • Capacitor Start and Run for reduced amperage
  • UL Recognized Component Listing and CSA approval
  • Non USA Manufactured, MX
Volts 115 Volts 230 Volts
F.L. Amps 3.8 F.L. Amps 1.9 F.L. Amps
S. F Amps 4.6 S. F Amps 2.3 S. F Amps
RPM 1800 Hertz 60
KW 0.25 Model # C4K17DC12A
Frame S56C Serv. Factor 1.35 Phase 1
Max Amb 40 Design N Code L
Insul Class B Protection NOT Therm.Prot.
Eff 100% 72.4 Eff 75%   PF 79
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number EXEMPT CE Yes Bearing PE 6203
Load Type   Inverter Type   Speed Range NONE
Motor Wt.   Enclosure DP Lubrication STANDARD
Nameplate 10000417-001-001 Mounting ROUND Rotation SELECTIVE CCW
Assembly   Shaft Dia.   Ext. Diag. A-005054.15-REGAL
Cust Part No   Outline A-SS404121-700 Ext. Diag2
1/3HP LEESON 1800RPM 56C ODP 115/230V 1PH ECOSAVER MOTOR E100024.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: E100024.00
Stock # E100024
Price: $267.00
Compare At: $608.00
