3/4HP LEESON 3000RPM 71 IP54 180VDC IEC PERMANENT MAGNET MOTOR 098017.00

Part Number:

098017.00

Model/Spec Number:

42D34FT2

Manufacturer:

Leeson Obsolete

098017.00 LEESON 3/4HP 180VDC Permanent Magnet Metric IEC Frame IP54 SCR Rated Motor is built to IEC 34-1 electrical and mechanical standards.

Item Discontinued

Click below to request an agent review potential options.

Shipping Details

Weight:

29 lbs

Dimensions:

8 x 17 x 8 inches

HS Code:

8501.31.4000

UPC:

691720001059

Technical Details

Specifications

Application:	General Purpose
Output HP:	3/4
Output KW:	0.55
Output RPM:	3000
Frame IEC:	71
Mount IEC:	Optional Mounting
Input Voltage DC:	180
Full Load Amps:	4.6
Winding:	Permanent Magnet
Enclosure NEMA:	TEFC

Documentation

Product Information Packet
