15HP BALDOR 1770RPM 254TC ODP 3PH MOTOR SUPER-E VEM2513T

15HP BALDOR 1770RPM 254TC ODP 3PH MOTOR SUPER-E VEM2513T

Picture is for reference only.

Part Number:

VEM2513T

Model/Spec Number:

39T032Y375G1

Manufacturer:

ABB/Baldor
VEM2513T BALDOR 15HP Three Phase Electric Motor is designed for pumps, fans, compressors, blowers, machine tools, conveyors and many other applications. Super-E Motors are designed to conserve energy over extended time periods.
MSRP: $4,433.00

Regular Price

USD

$

3,185

85

QTY
Login to View Discounts

Free No Rush Shipping

Weight:

234 lbs

Dimensions:

22 x 31 x 22 inches

HS Code:

8501.52.4000

UPC:

781568810576

Technical Details

Brand:

Baldor

Application:

General Purpose

Output HP:

15

Output KW:

11.2

Output RPM:

1770

Frame Size NEMA:

254TC

Mount NEMA:

C Face No Base

Enclosure NEMA:

ODP

Enclosure IEC:

IP22

Voltage:

230/460//190/380

VEM2513T-InfoPacket

APPLICATIONS: Typical applications include pumps, fans, compressors, blowers, industrial machines, conveyors and other general purpose applications. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2.

FEATURES:

  • Heavy duty frame
  • 1 5/8" Keyed output shaft
  • Optimized airflow design providing higher horsepower in a smaller package
