1.5HP BALDOR 1165RPM 182TC TEFC 3PH SUPER-E WASHDOWN EPOXY MOTOR CEWDM3607T

1.5HP BALDOR 1165RPM 182TC TEFC 3PH SUPER-E WASHDOWN EPOXY MOTOR CEWDM3607T

Picture is for reference only.

Part Number:

CEWDM3607T

Model/Spec Number:

36K190S916G1

Manufacturer:

ABB/Baldor
CEWDM3607T BALDOR 1.5HP 3PH SUPER-E WASHDOWN EPOXY ELECTRIC MOTOR is designed for use with food processing and other applications where motor is regularly exposed to high pressure wash down.
MSRP: $2,139.00

Regular Price

USD

$

1,537

23

QTY
Login to View Discounts

Free No Rush Shipping

Weight:

72 lbs

Dimensions:

16 x 26 x 18 inches

HS Code:

8501.52.4000

UPC:

781568817193

Technical Details

Brand:

Baldor

Application:

Washdown Epoxy

Output HP:

1.5

Output KW:

1.1

Output RPM:

1165

Frame Size NEMA:

182TC

Mount NEMA:

C Face With Base

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

Voltage:

230/460

CEWDM3607T-InfoPacket.pdf

APPLICATIONS: Designed for use with food processing and other applications where motor is regularly exposed to high pressure wash down.

FEATURES:

  • Moisture sealant on bolt heads, between frame and endplates
  • Neoprene gaskets
  • Double sealed bearings
  • Forsheda® running contact v-ring slinger
  • Stainless steel shaft
  • Electrostatically applied epoxy finish
  • Class F insulation
  • Tropicalized
