50HP WEG 1800RPM 326TS ODP 3PH MOTOR 05018OT3G326TS

50HP WEG 1800RPM 326TS ODP 3PH MOTOR 05018OT3G326TS

3PH GP ODP FOOTED CAST IRON 364-5TS FRAME.jpg
Picture is for reference only.

Part Number:

05018OT3G326TS

Model/Spec Number:

11877403

Manufacturer:

WEG
05018OT3G326TS WEG 50HP Three Phase General Purpose Cast Iron Motor is designed for environments where dirt and moisture are minimal. The ODP cast iron frame is designed to provide maximum ventilation and heat dissipation, offering low vibration levels, high mechanical stiffness and durability. Widely used in applications such as compressors, pumps and chillers, the ODP motor line meets or exceeds the efficiency levels determined by International Standards and the minimum efficiency level programs in force worldwide.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Free No Rush Shipping

Weight:

545 lbs

Dimensions:

32 x 40 x 32 inches

HS Code:

8501.52.0000

Technical Details

Brand:

WEG

Application:

General Purpose

Output HP:

50

Output KW:

36-39

Output RPM:

1775

Frame Size NEMA:

326TS

Mount NEMA:

With Base

Enclosure NEMA:

ODP

Enclosure IEC:

IP23

Voltage:

460//380
