5HP WEG 1730RPM W213/5T TEFC 1PH FARM DUTY MOTOR 00518ES1DFD215Z

Picture is for reference only.

Part Number:

00518ES1DFD215Z

Model/Spec Number:

10322192

Manufacturer:

Weg Obsolete

00518ES1DFD215Z WEG 5HP Single Phase General Purpose Cast Iron Motor provides high starting torque for the most demanding applications. Standard features such a v-rings provide versatility for indoor and outdoor applications.

Item Discontinued

Click below to view suggested functional replacement.

See Replacement Item

Shipping Details

Weight:

128 lbs

Dimensions:

16 x 26 x 18 inches

HS Code:

8501.40.6040

UPC:

7890705516479

Technical Details

Specifications

Application:	Farm Duty, General Purpose
Output HP:	5
Output KW:	3.7
Output RPM:	1730
Frame NEMA:	W213/5T
Mount NEMA:	Base Mount
Enclosure NEMA:	TEFC
Enclosure IEC:	IP55
Voltage:	230
Frequency (Hz):	60

Documentation

Product Information Packet

Additional Information

WEG Single Phase General Purpose Cast Iron Motor is the perfect option for applications that require robustness, low weight, and high performance in a single product. These rolled steel motors offer good thermal performance and easy installation and maintenance. Because of their high starting torque, they are particularly well suited for heavy starting loads.

Features:

Ball bearings
Class F insulation
F1 mounted
V-ring seals
NPT Threaded holes in terminal box
Cannot be modified with terminal box on the opposite side
These motors have a NEMA 215T base mounting pattern and shaft height of 5.25”, with usable length of 3 3/8” and diameter of 1 1/8” with standard key
Uses drip cover kit 175932.00
