SymCom 235P PumpSaver®Plus, 230VAC (5-15HP)

SymCom Model 235P single-phase PumpSaver®Plus is a pump monitor designed to protect single-phase pumps from dry-well, dead-head, jammed impeller, overvoltage and under voltage conditions. The PumpSaver®Plus Model 235P protects 230VAC, 5-15hp pumps. Typical applications include submersible pumps, centrifugal pumps, circulating pumps, cooling pumps, environmental pumps, residential water wells, commercial water wells, irrigation wells, and golf course systems.

SymCom's PumpSaver is a unique microcontroller-based voltage and current-sensing circuit constantly monitors the incoming power for fluctuations including over current, and undercurrent. When an abnormality, such as loss of suction, is detected, the PumpSaver® deactivates its output relay and directly disconnects the pump motor. The PumpSaver® then begins its user-selectable restart delay (dry-well recovery) timer. When the timer counts to zero or power is removed and reapplied, the PumpSaver® reactivates its output relay and turns the pump back on. An infrared LED communicates directly with a hand-held diagnostic tool called the Informer (sold separately). The Informer displays 15 parameters including calibration point, trip point, running points, and last fault.

Also available from SymCom is a easy to use hand held diagnostics tool called the INFORMER (sold separately). Infrared LED communicates directly with the PumpSaver Plus making it easy to diagnose those hassling pump issues.

USER Note: The use of flow restrictors, unusually high head pressures or low water conditions at the time of calibration may interfere with the detection of dead-head and dry-run conditions. Contact SymCom for information on activating the special under load high sensitivity mode built into this Pump Saver controller.

SymCom 235P PumpSaver®Plus, 230VAC (5-15HP)
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 235-P
Stock # PS235P
Price: $160.00
Compare At: $279.17
Quantity:
