STEARNS Injection Molded Class-B Coils

/

K4+ STEARNS Injection Molded 200VAC Class-B Coil 596642423

K4+ STEARNS Injection Molded 200VAC Class-B Coil 596642423

Picture is for reference only.

Part Number:

596642423

Model/Spec Number:

63420060944E

Manufacturer:

Stearns Obsolete

Manufacturer Part Number:

5-96-6424-23
5-96-6424-23 STEARNS #K4+ Class-B Injection Molded Coil 200VAC Genuine Replacement Part 63420060944E

Ordering Notes

Discontinued item with limited availability, subject to prior sale. Non-Returnable.

MSRP: $677.00

Regular Price

USD

$

285

00

QTY
Login to View Discounts

Weight:

2 lbs

Dimensions:

6 x 6 x 4 inches

HS Code:

8505907501

UPC:

793699000634

Technical Details

Stearns Series:

56000-56700

Static Torque Lb.-ft.:

15, 20

Coil Size:

#K4+

Enclosure NEMA:

NEMA2, NEMA4

Enclosure IEC:

IP23, IP54

Coil Voltage AC:

200//165VAC

Coil Hz:

60//50

Mount Orientation:

Horizontal/Vertical

Application:

General Purpose
