10HP MARATHON 1800RPM 215JM DP 230V 1PH MOTOR Z413

Catalog Number: Z413
Model Number: 215TBDW7027
Description: 10HP,1800RPM,215JM,230V,DP,1PH,60HZ
Ship Weight:  159 lbs.

This Marathon Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team

This Marathon motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

APPLICATIONS: Close-coupled pumps where the pump impeller is mounted directly on the
motor shaft in environments that are relatively clean and dry.

FEATURES:

  • C-Face with rigid base
  • Capacitor Start/Capacitor Run design for reduced amperage
  • NEMA JM pump shaft dimensions
  • Ball bearings, mechanically locked on shaft end
  • Continuous duty
  • 1.15 Service Factor
  • UL Recognized and CSA Certified
  • Footnote: 1

This product must be installed and serviced by a qualified technician, electrician, or electrical maintenance person familiar with its operation and the hazards involved. Proper installation, which includes electrical connections, fusing or other current protection, and grounding, can reduce the chance of electrical shocks, and fires, in this product or products used with this product, such as electric motors, switches, coils, solenoids, and relays. Do not use this product in an explosion-proof application.

Phase 1 Insulation Class F
Frame 215JM Duty CONTINUOUS
Enclosure DP Ambient 40
Mounting C-Face Rigid NEMA Design L
Orientation HORIZONTAL Starting Type CAP START CAP RUN
Assembly F1 ONLY KVA Code G
Drive End Bearing BALL IP Code 22
Opposite End Bearing BALL
Drive End Bearing Size 6309 Rotation SELECTIVE CCW
Opposite End Bearing Size 6206
Weight 159 LB lbs
CE Y CSA Y
UL Recognized Construction
Thermal Protection
10HP MARATHON 1800RPM 215JM DP 230V 1PH MOTOR Z413
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: Z413
Stock # Z413
Price: $1,193.00
Compare At: $2,748.00
