1.5HP MARATHON 1800RPM 145T 200-208V DP 3PH MOTOR U419
|Ship Weight:||39 lbs.|
This Marathon motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.
This product must be installed and serviced by a qualified technician, electrician, or electrical maintenance person familiar with its operation and the hazards involved. Proper installation, which includes electrical connections, fusing or other current protection, and grounding, can reduce the chance of electrical shocks, and fires, in this product or products used with this product, such as electric motors, switches, coils, solenoids, and relays. Do not use this product in an explosion-proof application.
APPLICATIONS: General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use.
- Rigid base
- Ball bearings
- 1.15 Service Factor
- Automatic thermal protection
- 7/8" shaft diameter
- Accepts C-face kit catalog number A436
- 56H, 143T, and 145T Combination Base with 12 mounting holes
- F1 Mounting only, cannot reassemble to F2
- Efficiency levels meet EISA requirements
- UL Recognized and CSA Certified
- Footnotes: 5,13
|Orientation||HORIZONTAL||Starting Type||ACROSS THE LINE|
|Assembly||F1 ONLY||KVA Code||M|
|Drive End Bearing||BALL||IP Code||22|
|Opposite End Bearing||BALL|
|Drive End Bearing Size||6205|
|Opposite End Bearing Size||6203|
|Weight||39 LB lbs|
|UL||Recognized Construction and Protector|
|Thermal Protection||Automatic Protector|
