3/4HP MARATHON 825RPM 56Y 208-230V DPAO 1PH MOTOR P246

Catalog Number:  P246
Model Number:  5KCP49UN9811S
Description:  3/4HP,825RPM,56Y,208-230V,DPAO,1PH,60HZ
Ship Weight:  32 lbs.

This Marathon motor is Non-Returnable.

Please take the time to identify your motor needs. It is the customer’s responsibility to review all product information provided to determine the correct mechanical and electrical characteristics needed for your application. If you need further assistance with this product to identify your product specifications, please contact our customer service department to answer any questions you may have.


APPLICATIONS: Direct drive condenser fan mounted vertically, shaft up or horizontal. This motor needs to be mounted within the airflow of the fan for proper cooling.

PERMANENT SPLIT CAPACITOR: Operates similarly to capacitor-start motors, but there is no centrifugal starting switch and what correspond to the "start" windings (second windings) are permanently connected to the power source (through a run capacitor), along with the run windings. PSC motors are frequently used in air handlers, blowers, and fans (including ceiling fans) and other cases where variable speeds are desired.


  • Capacitor not included
  • Automatic reset thermal protector
  • Enclosed shaft end bracket with vented frame
  • Horizontal or Shaft Up mounting
  • Single speed design
  • Ball bearings
  • 30" long leads
  • Shaft slinger
  • 40°C ambient
  • Flat & keyway on shaft
  • UL Recognized and CSA Certified

Phase 1 Insulation Class B
Frame 56Z Duty Continuous
Enclosure DP Ambient 40
Mounting RR NEMA Design -
Orientation Horizontal or Vertical Starting Type Squirrel Cage Induction
Assembly N/A KVA Code D
Drive End Bearing BALL IP Code N/A
Opposite End Bearing BALL
Drive End Bearing Size 6203 Rotation Select Clockwise
Opposite End Bearing Size 6203 Hazardous Location N/R
Weight 32 LB lbs
Thermal Protection Automatic
3/4HP MARATHON 825RPM 56Y 208-230V DPAO 1PH MOTOR P246
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: P246
Stock # P246
