5HP MARATHON 1800RPM 184TC 208-230V DP 1PH MOTOR I308

Catalog Number:  I308
Model Number:  184TBDR7634
Description:  5HP,1800RPM,184TC,208-230V,DP,1PH,60HZ
Design: CAPACITOR START
Ship Weight:  97 lbs.

This Marathon motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

This Marathon Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team





APPLICATIONS: General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use.

FEATURES:

  • C-Face Footed
  • Capacitor Start/Capacitor Run design for reduced amperage
  • Manual overload protection
  • Heavy gauge steel frame and base
  • Pressure washer duty
  • Ball bearings
  • UL Recognized and CSA Certified
  • Footnote: 1

Phase 1 Insulation Class B
Frame 184TC Duty CONTINUOUS
Enclosure DP Ambient 40
Mounting C-Face Rigid NEMA Design NO DESIGN CODE
Orientation HORIZONTAL Starting Type CAP START CAP RUN
Assembly F1 ONLY KVA Code N/A
Drive End Bearing BALL IP Code 22
Opposite End Bearing BALL
Drive End Bearing Size 6207 Rotation SELECTIVE CW
Opposite End Bearing Size 6205
Weight 97 LB lbs
CE N/A CSA Y
UL N/A
Thermal Protection Manual Protector
5HP MARATHON 1800RPM 184TC 208-230V DP 1PH MOTOR I308
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: I308
Stock # I308
Price: $748.00
Compare At: $1,722.00
