2HP MARATHON 3600RPM 145JPV TEFC 230/460V 3PH MOTOR GT5406

Catalog Number: GT5406
Model Number: 145TTFR16015
Description: 2HP,3600RPM,145JP,230/460V,TEFC,3PH,60/50HZ
Ship Weight: 52 lbs.

APPLICATIONS: Close-coupled pump where the pump impeller is mounted directly on the
motor shaft in environments that are relatively clean and dry.

FEATURES:

  • C-Face Footless
  • Meets or exceeds NEMA Premium® efficiencies
  • NEMA Premium® models are in compliance with EISA2007
  • Inverter Duty 10:1 Variable Torque and 2:1 Constant Torque, 1.0 SF
  • 1.15 Service Factor
  • Class F Insulation
  • Standard assembly F1, reversible to F2 assembly
  • Nameplated 60/50 hertz, 190/380 volts at next lower HP
  • Three year warranty

This product must be installed and serviced by a qualified technician, electrician, or electrical maintenance person familiar with its operation and the hazards involved. Proper installation, which includes electrical connections, fusing or other current protection, and grounding, can reduce the chance of electrical shocks, and fires, in this product or products used with this product, such as electric motors, switches, coils, solenoids, and relays. Do not use this product in an explosion-proof application.

Phase 3 Insulation Class F
Frame 145JPV Duty CONTINUOUS
Enclosure TEFC Ambient 40
Mounting C-Face Footless NEMA Design B
Orientation HORIZONTAL OR SHAFT DOWN Starting Type LINE OR INVERTER
Assembly F1 ONLY KVA Code K
Drive End Bearing BALL IP Code 43
Opposite End Bearing BALL
Drive End Bearing Size 6206
Opposite End Bearing Size 6203
Weight 52 LB lbs Inverter Speed Range CONSTANT 2:1
CE Y CSA Y
UL Recognized Construction
Thermal Protection
2HP MARATHON 3600RPM 145JPV TEFC 230/460V 3PH MOTOR GT5406
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: GT5406
Stock # GT5406
Price: $494.00
Compare At: $1,137.00
