1/4HP MARATHON 1140RPM 56C 115/208-230V TEFC 1PH MOTOR G577
| Catalog Number: | G577 |
| Model Number: | 056C11F5302 |
| Description: | 1/4HP,1140RPM,56C,115/208-230V,TEFC,1PH,60HZ |
| Design: | CAPACITOR START |
| Ship Weight: | 24 lbs. |
APPLICATIONS: General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use.
FEATURES:
- No overload protection
- Four in One design
- Capacitor start design for high starting torque
- Double sealed ball bearings, mechanically locked on shaft end
- Heavy gauge steel constructions
- Bolt-on, removable rigid base
- Suitable for horizontal or vertical mounting
- 1.15 Service Factor
- Will accept brake kits
- Will accept drip cover kits
- UL Recognized and CSA Certified
| Phase | 1 | Insulation Class | B |
|---|---|---|---|
| Frame | 56C | Duty | CONTINUOUS |
| Enclosure | TEFC | Ambient | 40 |
| Mounting | C-Face - Removable Base | NEMA Design | N |
| Orientation | HORIZONTAL | Starting Type | CAP START IND RUN |
| Assembly | F1 ONLY | KVA Code | N |
| Drive End Bearing | BALL | IP Code | 43 |
| Opposite End Bearing | BALL | ||
| Drive End Bearing Size | 6203 | Rotation | SELECTIVE CCW |
| Opposite End Bearing Size | 6203 | ||
| Weight | 24 LB lbs | ||
| CE | Y | CSA | Y |
| UL | Recognized Construction | ||
| Thermal Protection | |||
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: G577
Stock # G577
