1HP LINCOLN 3450RPM 56C DP 3PH SIGNATURE SERIES MOTOR LM24884
1HP LINCOLN 3450RPM 56C DP 3PH SIGNATURE SERIES MOTOR LM24884
Picture is for reference only.
Part Number:
LM24884Manufacturer:
LincolnManufacturer Part Number:
LM24884This product has been discontinued with no direct replacement from the manufacturer. The functional equivalent should be reviewed for application compatibility.
Click below to view suggested functional replacement.
Shipping Details
Dimensions:
12 x 20 x 12 inchesTechnical Details
Specifications
Brand: | Lincoln |
Application: | General Purpose |
Output HP: | 1 |
Output KW: | 0.75 |
Output RPM: | 3450 |
Frame Size NEMA: | 56C |
Mount NEMA: | C Face With Base |
Enclosure NEMA: | EPFC, DP, OPEN |
Enclosure IEC: | IP22 |
Voltage: | 230/460 |
Documentation
Additional Information
| Volts | 230 | Volts | 460 | Volts | 190-208/380-415 |
| F.L. Amps | 3.7 | F.L. Amps | 1.85 | F.L. Amps | 3.6-4.0/1.8-2.0 |
| S. F Amps | 4.0 | S. F Amps | 2.0 | S. F Amps | |
| RPM | 3600 | Hertz | 60/50 | ||
| HP | 1 | Duty | CONTINUOUS | TYPE | TS |
| KW | .746 | ||||
| Frame | 56C | Serv. Factor | 1.25 | Phase | 3 |
| Max Amb | 40 | Design | B | Code | M |
| Insul Class | B | Protection | NOT | Therm.Prot. | |
| Eff 100% | 74 | Eff 75% | PF | ||
| UL | V-INS, CONST UL REC | CSA | Yes | Bearing OPE | 203 |
| CC Number | CE | No | Bearing PE | 203 | |
| Load Type | Inverter Type | NONE | Speed Range | UNK | |
| Motor Wt. | 23 LB | Enclosure | DP | Lubrication | STANDARD |
| Nameplate | Mounting | RIGID | Rotation | REV |
This product has been discontinued with no direct replacement from the manufacturer. The functional equivalent should be reviewed for application compatibility.
Click below to view suggested functional replacement.
Shipping Details
Dimensions:
12 x 20 x 12 inches
