1/2HP LINCOLN 1750RPM 56C TEFC 3PH Inverter Duty Motor LM24264

1/2HP LINCOLN 1750RPM 56C TEFC 3PH Inverter Duty Motor LM24264

Picture is for reference only.

Part Number:

LM24264

Model/Spec Number:

SRF4S0.5TC61Q20

Manufacturer:

Lincoln

Manufacturer Part Number:

LM24264
LM24264 LINCOLN 1/2HPlectric Motors for use in extruders, conveyors, machine tools and other process industries with constant torque, variable speed loads.

Item Discontinued

Click below to request an agent review potential options.

Weight:

26 lbs

Dimensions:

12 x 20 x 12 inches

HS Code:

8501.51.4000

UPC:

691720305492

Technical Details

Brand:

Lincoln

Output HP:

1/2

Output KW:

0.37

Output RPM:

1750

Frame Size NEMA:

56C

Mount NEMA:

With Base

Enclosure NEMA:

TEFC

Voltage:

230/460

Frequency (Hz):

60

Inverter Rating:

Inverter Ready

Motor Drawing

Connection Diagram

Volts 230 Volts 460 Volts
F.L. Amps 2.4 F.L. Amps 1.2 F.L. Amps
S. F Amps   S. F Amps   S. F Amps
RPM 1800 Hertz 60
HP 1/2 Duty CONTINUOUS TYPE TS
KW .373
Frame 56 C Serv. Factor 1.0 Phase 3
Max Amb 40 Design B Code M
Insul Class F Protection NOT Therm.Prot.
Eff 100% 68 Eff 75%   PF 61.1
UL V-OVER TEMP PROT 3, P1-P2 CSA Yes Bearing OPE 203
CC Number EXEMPT CE No Bearing PE 203
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 24 LB Enclosure TEFC Lubrication STANDARD
Nameplate   Mounting RIGID Rotation REV
