7.5HP LINCOLN 1170RPM 254TC TEFC 3PH Inverter Duty Motor LM22834

7.5HP LINCOLN 1170RPM 254TC TEFC 3PH Inverter Duty Motor LM22834

Picture is for reference only.

Part Number:

LM22834

Model/Spec Number:

AF6P7.5TC61Q40

Manufacturer:

Lincoln
LM22834 LINCOLN 7.5HP Three Phase Inverter Duty Electric Motor is for use in constant torque (conveyors, machine tools) or variable torque (pumps, fans) variable speed applications within the stated speed range of the motor.

Item Discontinued

Click below to request an agent review potential options.

Weight:

221 lbs

Dimensions:

24 x 32 x 24 inches

Technical Details

Brand:

Lincoln

Application:

Inverter Duty

Output HP:

7.5

Output KW:

5.5

Output RPM:

1025-1295 (6P)

Frame Size NEMA:

254TC

Mount NEMA:

C Face With Base

Enclosure NEMA:

TEFC

Voltage:

230/460

Frequency (Hz):

60
