3HP LINCOLN 1170RPM 213TC TEFC 3PH MOTOR LM22828

LINCOLN Catalog Number:  LM22828
Description:  3HP,1170RPM,213TC,TEFC,3PH,60HZ
Ship Weight:  138 lbs.



This Lincoln Motor is a Build To Order product and factory lead times are approximately 4-7 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales office for particulars.

Subject to availability, call for lead times.

TEFC C-FACE Models: For use in constant torque (conveyors, machine tools) or variable torque (pumps, fans) variable speed applications within the stated speed range of the motor.

Features Include:

  • Made in the U.S.A.
  • Variable torque speed range with open loop drive of 0-60Hz.
  • Constant horsepower speed range of 2x base speed (56-256T frames) or 1.5x base speed (284T-449T frames)
  • Wider speed ranges possile on intermittent duty.
  • Ultimate Spike Defense Insulation System
  • 1.00 service factor on PWM waveform, 1.15 service factor or better on sine-wave power.
  • Precision dynamic balanced rotor assembly
  • Thermal overload protection (Class F Thermostats)
3HP LINCOLN 1170RPM 213TC TEFC 3PH MOTOR LM22828
Click Image to Enlarge
Picture is for quick refrence only
Manufacturer Part Number: LM22828
Stock # LM22828
