75HP LINCOLN 1750RPM 365T DP 230/460V 3PH MOTOR LM21124

Catalog Number: LM21124
Model Number: SD4P75T61YQ40
Description:  75HP,1750RPM,365T,DP,230/460V,3PH,60HZ
Ship Weight:  763 lbs.

This Lincoln motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

This LINCOLN Motor Can Ship Ground Freight ONLY!

For expedited needs please contact our sales team for freight options.

APPLICATIONS: For use in constant torque (conveyors, machine tools) or variable torque (pumps, fans)  variable speed applications within the stated speed range of the motor.

Features Include:

  • Made in the U.S.A.
  • Steel Frame design
  • 10:1 Constant torque speed range at continuous duty of 6-60Hz
  • Variable torque speed range with open loop drive of 0-60Hz
  • Constant horsepower speed range of 2x base speed
    (56-256T frames) or 1.5x base speed (284T-449T frames)
  • Ultimate Spike Defense Insulation System
  • 1.00 service factor on PWM waveform (Frequency drive)
  • 1.15 service factor or better on sine-wave power
  • Precision dynamic balanced rotor assembly
  • Thermal overload protection (Class F Thermostats)
  • Warranty: 42 months from date of manufacture and 36 months
    from date of installation which ever period expires first
Volts 230 Volts 460 Volts
F.L. Amps 176 F.L. Amps 88 F.L. Amps
S. F Amps   S. F Amps   S. F Amps
RPM 1800 Hertz 60
HP 75 Duty CONTINUOUS TYPE TDR
KW 56.0
Frame 365T Serv. Factor 1.0 Phase 3
Max Amb 40 Design B Code G
Insul Class F Protection NOT Therm.Prot.
Eff 100% 95 Eff 75%   PF 84
UL V-INS, CONST UL REC CSA Yes Bearing OPE 6311
CC Number CC004A CE Yes Bearing PE 6313
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 763 LB Enclosure DP Lubrication STANDARD
Nameplate 3B452-AZ-X-BCDLM-A-X Mounting RIGID Rotation REV
75HP LINCOLN 1750RPM 365T DP 230/460V 3PH MOTOR LM21124
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: LM21124
Stock # LM21124
Price: $5,579.00
Compare At: $14,087.00
