40HP LINCOLN 1780RPM 324T TEFC 3PH PREMIUM MOTOR LM19750

Picture is for reference only.

Part Number:

LM19750

Model/Spec Number:

CCF4B40T61Y

Manufacturer:

Lincoln

LM19750 LINCOLN 40HP PREMIUM motor carries a three-year warranty in general purpose and inverter fed applications. This motor meets or exceeds most utility rebate programs and the EPACT federally mandated efficiency levels.

Item Discontinued

Click below to view suggested functional replacement.

See Replacement Item

Shipping Details

Weight:

835 lbs

Dimensions:

24 x 36 x 24 inches

HS Code:

8501.52.0000

Technical Details

Specifications

Brand:	Lincoln
Application:	General Purpose
Output HP:	40
Output KW:	30.0
Output RPM:	1780
Frame Size NEMA:	324T
Mount NEMA:	With Base
Enclosure NEMA:	TEFC
Enclosure IEC:	IP43
Voltage:	230/460

Documentation

Motor Drawing REF DASH-1300

Connection Diagram

Additional Information

Volts	230	Volts	460	Volts
F.L. Amps	95	F.L. Amps	47.5	F.L. Amps
S. F Amps	108	S. F Amps	54	S. F Amps

RPM	1800	Hertz	60
HP	40	Duty	CONTINUOUS	TYPE	TFS
KW	29.84
Frame	324T	Serv. Factor	1.15	Phase	3
Max Amb	40	Design	B	Code	G
Insul Class	F	Protection	NOT	Therm.Prot.
Eff 100%	94.1	Eff 75%		PF	83
UL	V-INS, CONST UL REC	CSA	Yes	Bearing OPE	311
CC Number	CC004A	CE	Yes	Bearing PE	312
Load Type		Inverter Type	NONE	Speed Range	NONE

Motor Wt.	726 LB	Enclosure	TEFC	Lubrication	STANDARD
Nameplate		Mounting	RIGID	Rotation	REV
