3/4HP LINCOLN 1750RPM 56HC TEFC 3PH Inverter Duty Motor LM10339

3/4HP LINCOLN 1750RPM 56HC TEFC 3PH Inverter Duty Motor LM10339

Picture is for reference only.

Part Number:

LM10339

Model/Spec Number:

SRF4S0.75TC61Q20

Manufacturer:

Lincoln

Manufacturer Part Number:

LM10339
LM10339 LINCOLN 3/4HP Electric Motors for use in extruders, conveyors, machine tools and other process industries with constant torque, variable speed loads.

Item Discontinued

Click below to request an agent review potential options.

Weight:

27 lbs

Dimensions:

12 x 20 x 12 inches

HS Code:

8501.51.4000

UPC:

691720060483

Technical Details

Brand:

Lincoln

Output HP:

3/4

Output KW:

0.55

Output RPM:

1750

Frame Size NEMA:

56HC

Mount NEMA:

C Face With Base

Enclosure NEMA:

TEFC

Voltage:

230/460

Frequency (Hz):

60

Inverter Rating:

Inverter Ready

Motor Drawing

Connection Diagram

Volts 230 Volts 460 Volts 200/400
F.L. Amps 3 F.L. Amps 1.5 F.L. Amps 3/1.5
S. F Amps   S. F Amps   S. F Amps
RPM 1800 Hertz 60/50
HP 3/4 Duty CONTINUOUS TYPE TS
KW .56
Frame 56HC Serv. Factor 1.0 Phase 3
Max Amb 40 Design B Code L
Insul Class F Protection NOT Therm.Prot.
Eff 100% 75.5 Eff 75%   PF 66.3
UL NONE-OVER TEMP PROT 3, P1-P2 CSA Yes Bearing OPE 203
CC Number EXEMPT CE Yes Bearing PE 203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 25 LB Enclosure TEFC Lubrication STANDARD
Nameplate   Mounting RIGID Rotation REV
