LENZE 1HP SCM VFD 200-240V 1PH INPUT SM210S
|Output Amps 230V:||4.2|
|Output Amps 208V:||4.8|
|Ship Weight:||3 lbs.|
LENZE AC TECH SCM IP20 Frequency Drives are designed for compact packaging and comprehensive functionality make the SCM and SCL an ideal drive solution for use on equipment requiring variable speed, soft starting or reversing operation. Lenze SCL & SCM frequency drives are easy to configure and ready to use right out of the box for most simple applications. By simple reprogramming, the SCM and SCL will perform many application specific tasks such as multiple preset speeds, electronic braking and motor jogging to name a few. Like all AC Tech sub-micro drives, the SCM and SCL drives use the EPM memory technology for fast and efficient programming.
- Digital Inputs
- 1 Run/Stop
- 3 Programmable
- 1 Form A relay
- 1 voltage (0-10VDC)
- 1 current (4-20mA)
- Speed Potentiometer Power Supply
- Signal Common
- Digital Input Reference
EMC Filter: Standard on SCL
- Carrier Freq. 4 – 10 kHz
- Independent Accel and Decel Ramps
- 2nd Accel / decal ramp
- Auxiliary Ramp to Stop
- 240 Hz Maximum Output Freq.
- DC Injection Braking
- JOG (Fwd or Rev)
- Floating Point Control (MOP)
- 0-10 VDC Analog Reference (scalable)
- 4-20 mA Analog Reference (scalable)
- 8 Programmable Preset Speeds
Standards and Conformance
- UL & cUL (North America)
- CE (Europe)
- Low Voltage Directive (EN61800-5-1)
- EMC Directive (EN61800-3) when suitably filtered
Remote Keypad: Simple 4 wire connection to the SCM or SCL drive, the remote keypad provides for drive operation (start, stop, direction and speed) and programming. Includes 3 digit LED. Measures only 3.4in (H) x2.2 in (W). Includes gasketing to meet up to NEMA 4X rated environments.
Dynamic Braking: Packaged Dynamic brake option includes control and resistors in an easy to implement solution for fast stopping or deceleration requirements.
EMC Filter: To meet the EU requirements for susceptibility and emissions of electrical and radiated noise (EN 61800-3 and EN 5501). The footprint design allows the filter to mount between the panel and the drive providing the most efficient use of panel space.
