LEESON Catalog Number: M1125282.00
Description: 1/15HP,19RPM,38,TENV,208-230V,3PH,60HZ,PARALLEL
Ship Weight: 10 lbs.

This Leeson Gearmotor is a Build To Order product and factory lead times are approximately 3-6 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales office for particulars.

Design Specifications: Three phase Inverter Rated Gear Motor totally enclosed for continuous duty, general purpose applications. Standard on all these ratings is the exclusive Inverter Rated Insulation System (IRIS). This provides superior protection against voltage spikes induced by variable frequency drives. Many superior mechanical features for both the motor and gearbox. Double shielded ball bearings in the motor. Needle bearings in the parallel shaft gearboxes and ball bearings in the Right angel (worm) gearboxes. Steel conduit box provided as standard. Complete gearmotor furnished with high gloss hardened black enamel paint.

Application Notes: These motors are designed with high temp insulation 9 (Class F) to avoid over heating when operated with a PWM inverter down to a 10:1 speed range from the printed gearmotor output RPM. The torque values listed are the recommended full load torque values for reasonable gear life. Overhung load capacities shown are at the center of the output shaft.

RPM 19 Volts   Volts 208-230
HPKW .067 F.L. Amps   F.L. Amps .4
Frame 31 S. F Amps   S. F Amps
Max Amb 40 Hertz   Phase 3
Insul Class F4 Duty CONT TYPE TN
Model # CM31T17NZ26A Serv. Factor 1 PF
Eff 100%   Eff 75%   Enclosure TENV
Protection NOT Therm.Prot.   Bearing OPE R6
Design   Code H Bearing PE 6000
UL Yes CSA Yes CE No
Torque lb-In 100 Nameplate 081188.01 Lubrication
Series PZ Overrlung Ld. 155 Shaft Type PARALLEL
Motor Wt. 10 LB Mounting SPECIAL Rotation RECONN
Click Image to Enlarge
Manufacturer Part Number: M1125282.00
Stock # M1125282
Price: $345.00
Compare At: $869.00
