1/8HP LEESON 14RPM TENV 12VDC WASHDOWN PE350 PARALLEL GEARMOTOR M1125273.00

LEESON Epoxy IP55 Washguard PE350 Series DC Gearmotor for applications requiring superior resistance to moisture, acids, alkalies, and oils. Performance matched for continuous duty service. Designed for battery power or can be used with a low voltage controller with form factor up to 1.05.

Features:

• Gearbox output shafts are coated with Microlon® 3300 fortified Teflon® for superior corrosion resistance
• Frame, endshields, armature and interior components protected by enamel and polyester compounds for resistance to moisture, acids, alkalies and oil
• Precision machined in-line steel gears
• First stage steel helical gear followed by spur-type gears
• Lubrication is permanent semi-fluid grease, reducing possibility of leakage
• Output shafts have needle bearings for high load capacities
• Gearbox Shafts are hardened steel
• Cast conduit box with threaded conduit holes and nitrile gaskets keep water out
• Conduit box cover is made from 304 stainless steel
• For any condensation that may accumulate inside the motor, a one-way stainless steel vapor vent is provided
• All hardware is stainless steel
• Painted with white epoxy for superior corrosion resistance and protection
• Machined fits between the endbells and motor frame are sealed with gaskets
• Thru-bolt heads and nuts sealed with fiber washers
• O-ring under each threaded brush cover

Application Notes:

• Extended life in wet, high humidity applications
• Design repels water from entering motor
• Internal components protected against rust and corrosion
• Placing the gearmotor with the motor below the gearbox (shaft up with gearmotor below) should be avoided to prevent leakage of lubricant into the motor should the motor shaft seal fail
• Overhung load capacities shown are at center of output shaft
• Motor’s stall torque could exceed recommended full load torques. A current limiting device such as an SCR control should be used to prevent damage. This issue is even more critical for low voltage motors, typically no controller is used since motor is connected directly to a battery, so some type of current limit or fusing should be considered
• USDA Approved white epoxy finish
