10HP LEESON 3600RPM 215JM TEFC 3PH PUMP MOTOR G140734

LEESON 140734.00 has been Superseded by G140734.00

Catalog Number: G140734.00
Model Number: C215T34WK5
Description:  10HP,3600RPM,215JM,3PH,60HZ,EPOXY WASHGUARD
Ship Weight: 109 lbs.

This LEESON Motor Can Ship Ground Freight ONLY!

For expedited needs please contact our sales team for freight options.

WASHGUARD WHITE EPOXY: Washdown duty three phase JM Frame pump motors for industrial service. These motors include all of the features of LEESON's White Duck WASHGUARD EPOXY motors with the addition of a JM pump frame shaft for use on closed coupled pumps. For demanding pump applications in wet, humid, or washdown environments.

Volts 208-230 Volts 460 Volts
F.L. Amps 27-24 F.L. Amps 12 F.L. Amps
S. F Amps 30.5-27 S. F Amps 13.5 S. F Amps
RPM 3600 Hertz 60
HP 10 Duty CONTINUOUS TYPE TF
KW 7.5 Model # C215T34WK5A
Frame 215JM Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code G
Insul Class F Protection NOT Therm.Prot.
Eff 100% 89.5 Eff 75%   PF 87
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 206
CC Number CC005A CE Yes Bearing PE 309
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 109 LB Enclosure TEFC Lubrication STANDARD
Nameplate 081292 Mounting RIGID Rotation REV
10HP LEESON 3600RPM 215JM TEFC 3PH PUMP MOTOR G140734
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: G140734.00
Stock # G140734
