7.5HP LEESON 1800RPM 213JM TEFC 3PH MOTOR G140733.00

LEESON G140733.00 has been Superseded by 141270.00

Catalog Number:  G140733.00
Model Number: C213T17WK13
Description:  7.5HP,1800RPM,213JM,TEFC,3PH,EPOXY WASHGUARD
Ship Weight: 135 lbs.
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 24-22 F.L. Amps 11 F.L. Amps 18/9
S. F Amps 26-24 S. F Amps 12 S. F Amps 20/10
RPM 1800 Hertz 60/50
HP 7 1/2 Duty CONTINUOUS TYPE TF
KW 5.6 Model # C213T17WK13 A
Frame 213JM Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code H
Insul Class F Protection NOT Therm.Prot.
Eff 100% 89.5 Eff 75%   PF 72
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6206
CC Number EXEMPT CE Yes Bearing PE 6209
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 133.5 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 081292 Mounting RIGID C Rotation REV
7.5HP LEESON 1800RPM 213JM TEFC 3PH MOTOR G140733.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: G140733.00
Stock # G140733
