10HP LEESON 1760RPM 215TC TEFC 3PH BRAKE MOTOR G140639.00

Catalog Number:  G140639.00
Model Number:  C215T17FK6B
Description:  10HP,1760RPM,215TC,TEFC,3PH,60HZ,BRAKE
Ship Weight:  178 lbs.
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 29-28 F.L. Amps 14 F.L. Amps 26/13
S. F Amps 31-30 S. F Amps 15 S. F Amps 28/14
RPM 1800 Hertz 60/50
HP 10 Duty CONTINUOUS TYPE TF
KW 7.50 Model # C215T17FK6B
Frame 215TC Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code J
Insul Class F Protection NOT Therm.Prot.
Eff 100% 89.5 Eff 75%   PF 76
UL Yes CSA Yes Bearing OPE 6206
CC Number 005A CE Yes Bearing PE 6207
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 178 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 081284 Mounting RIGID C Rotation REV
10HP LEESON 1760RPM 215TC TEFC 3PH BRAKE MOTOR G140639.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: G140639.00
Stock # G140639
