1/2HP LEESON 1725RPM 56C DP 1PH ECOSAVER MOTOR E100020.00

Catalog Number:  E100020.00 - FREE Ground Shipping in USA
Model Number:  A4K17DC22A
Description:  1/2HP,1725RPM,56C,DP,1PH,60HZ,ECOSAVER
Ship Weight:  23 lbs.

LEESON Single Phase ECOSAVER Motors satisfies the mandated efficiencies of NEMA Premium and carries a three year warranty. For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans and other standard industrial applications.

FEATURES:

  • Durable rolled steel frame
  • 5/8" Keyed output shaft
  • Automatic overload protection
  • Double-shielded ball bearings
  • Capacitor Start
  • UL Recognized Component Listing and CSA approval
  • Non-USA Manufactured, MX.
Volts 115   Volts 230   Volts
FL Amps 4.6   FL Amps 2.3   FL Amps
SF Amps 5.6   SF Amps 2.8   SF Amps
RPM 1800   Hertz 60
HP 1/2   Duty CONTINUOUS   Type KD
KW 0.37   SF 1.25   Phase 1
Frame S56C   Design N   KVA Code K
Ambient 40   Protection AUTOMATIC   Therm.Prot. CEG69GV
Insulation Class B   Eff(75%)     PF 91.6
Eff(100%) 76.2   CSA Y   Bearing OPE 6203
UL Y-(LEESON UL REC)   CE Y   Bearing PE 6203
CC Number EXEMPT   Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 23 LB   Enclosure DP   Lubrication MULTEMP SRL
Nameplate 92005-271   Mounting ROUND   Rotation SELECTIVE CCW
Shaft Diam.     Cust Part No.     Packaging F
      Winding BE484110   Carton Label
      Group 3   Iris
Paint GREEN - LEESON WATTSAVER   Hazardous Location NONE   Test Card
1/2HP LEESON 1725RPM 56C DP 1PH ECOSAVER MOTOR E100020.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: E100020.00
Stock # E100020
Price: $262.00
Compare At: $661.00
