30HP LEESON 1770RPM 286T TEFC 3PH IEEE 841 SEVERE DUTY MOTOR 811561.00

30HP LEESON 1770RPM 286T TEFC 3PH IEEE 841 SEVERE DUTY MOTOR 811561.00

Picture is for reference only.

Part Number:

811561.00

Model/Spec Number:

286THFNA19051

Manufacturer:

Leeson Obsolete
811561.00 LEESON 30HP IEEE 841 Premium Severe Duty Motor is designed for harsh environments that you may find in refineries, above-ground mines, foundries, paper and pulp mills, cement plants or other severe duty applications.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

555 lbs

Dimensions:

26 x 35 x 26 inches

HS Code:

None

UPC:

691720247327

Technical Details

Brand:

Leeson

Application:

IEEE 841, Severe Duty

Output HP:

30

Output KW:

22.4

Output RPM:

1773

Frame Size NEMA:

286T

Mount NEMA:

With Base

Enclosure NEMA:

TEFC

Enclosure IEC:

IP56

Voltage:

460

Product Information Packet
