1/2HP LEESON 1800RPM 56C TENV 1PH MOTOR 6439191260

Catalog Number:  6439191260 - FREE Ground Shipping In USA
Model Number:  C6C17NC107A
Description:  1/2HP,1800RPM,56C,TENV,1PH,60HZ,BOAT HOIST
Ship Weight:  28 lbs.

LEESON/ELECTRA Single Phase Stainless Steel Boat Hoist Motors provide customized features that are needed to support the Boat Hoist Industry.

FEATURES:

  • Stainless Steel frame, capacitor case and conduit box cover
  • 15 Minute Duty Cycle
  • 5/8" Keyed output shaft
  • Base-less design
  • Drain Holes located at 6:00 position
  • TENV enclosure
  • Die Cast Aluminum endbells
  • Capacitor case located at 12:00
  • 115/230 Volt - 1.15 Service Factor
  • Non USA Manufactured, CN
  • UL and CSA listed
Volts 115   Volts 230   Volts
FL Amps 8.2   FL Amps 4.1   FL Amps
SF Amps 9.4   SF Amps 4.7   SF Amps
RPM 1800   Hertz 60
HP 1/2   Duty 15 MINUTE   Type CN
KW .37   SF 1.15   Phase 1
Frame 56C   Design N   KVA Code L
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class B   Eff(75%)     PF 65
Eff(100%) 61   CSA Y   Bearing OPE 6203
UL Y-(LEESON UL REC)   CE Y   Bearing PE 6203
CC Number EXEMPT   Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 28 LB   Enclosure TENV   Lubrication POLYREX EM
Nameplate     Mounting ROUND   Rotation SELECTIVE CCW
Shaft Diam. 5/8 IN   Cust Part No.     Packaging B
      Winding QC63417   Carton Label
      Group 3   Iris
Paint NO PAINT   Hazardous Location NONE   Test Card 01
1/2HP LEESON 1800RPM 56C TENV 1PH MOTOR 6439191260
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 6439191260
Stock # 6439191260
Price: $202.00
Compare At: $509.00
