20HP LEESON 3600RPM 254JM DP 3PH MOTOR 199965.00

Catalog Number:  199965.00 -FREE Ground Shipping in USA
Model Number:  C254T34DK9
Description:  20HP,3600RPM,254JM,DP,3PH,60HZ,JM PUMP
Ship Weight:  312 lbs.

This Leeson motor is a Build To Order product and factory lead times are approximately 4-6 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

LEESON Three Phase Premium Pump Motors are designed for continuous duty service on close-coupled pumps using NEMA JM mounting provisions. All motors have a rigid mounting base and NEMA JM pump Shaft.

FEATURES:

  • Cast Iron frame
  • C-Face no base
  • Open drip-proof construction
  • Cooling air exhausts at the shaft end for maximum cooling
  • Oversized locked bearing on shaft end limits axial shaft movement
  • High efficiency copper windings with NEMA 1.15 service factors
  • UL and CSA recognized designs
  • Non USA Manufactured, CN
Volts 230   Volts 460   Volts 190/380
FL Amps 45   FL Amps 22.5   FL Amps 41/20.5
SF Amps 51.5   SF Amps 25.8   SF Amps
RPM 3600   Hertz 60/50
HP 20   Duty CONTINUOUS   Type TD
KW 14.9   SF 1.15   Phase 3
Frame 254JM   Design B   KVA Code G
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class F   Eff(75%)     PF 89.5
Eff(100%) 91.7   CSA Y   Bearing OPE 6208
UL Y-(LEESON UL REC)   CE Y   Bearing PE 6209
CC Number CC005A   Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 320 EA   Enclosure DP   Lubrication VERIFY
Nameplate 93405-L-N-ABDFH-C-D   Mounting RIGID   Rotation REV
Shaft Diam.     Cust Part No.     Packaging N
      Winding CHT25420003   Carton Label
      Group 1   Iris
Paint BLUE (ENAMEL)   Hazardous Location NONE   Test Card
20HP LEESON 3600RPM 254JM DP 3PH MOTOR 199965.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 199965.00
Stock # 199965
Price: $745.00
Compare At: $3,418.00
