7.5HP LEESON 1800RPM 213JP DP 3PH MOTOR 199783.00

Discontinued - Subject to availability

Catalog Number:  199783.00 -FREE Ground Shipping in USA
Model Number:  C213T17DK47
Description:  7.5HP,1800RPM,213JP,DP,3PH,60HZ,JP PUMP
Ship Weight:  166 lbs.

This Leeson Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

LEESON Three Phase JP Pump Motors are designed for continuous duty service on close-coupled pumps using NEMA JP mounting and shaft dimensions. In such applications, the pump impeller is mounted directly on the motor shaft. Designed for continuous duty service. All motors listed are 1.15 Service Factor.

FEATURES:

  • Open drip-proof construction with rigid base mounting
  • Locked bearing on shaft end limits axial shaft movement
  • For use where the environment is relatively clean and dry
  • For outdoor use, an enclosure or drip cover may be preferred
  • Drip cover not included. Use drip cover part number 175846.00
  • High efficiency copper windings with NEMA 1.15 service factors
  • UL and CSA recognized designs
  • All 180 and 210 frame rolled steel motors have Class F Insulation
  • Non-USA Manufactured, CN
Volts 230   Volts 460   Volts 190/380
FL Amps 19   FL Amps 9.5   FL Amps 15.2/7.6
SF Amps 22   SF Amps 11   SF Amps 17.6/8.8
RPM 1800   Hertz 60/50
HP 7 1/2   Duty CONTINUOUS   Type TD
KW 5.6   SF 1.15   Phase 3
Frame 213JP   Design B   KVA Code H
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class F   Eff(75%)     PF 81
Eff(100%) 91.7   CSA Y   Bearing OPE 6206
UL Y-(LEESON UL REC)   CE Y   Bearing PE 6309
CC Number CC005A   Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 166 LB   Enclosure DP   Lubrication VERIFY
Nameplate 93405-L-N-ABDFH-B-D   Mounting RIGID   Rotation REV
Shaft Diam.     Cust Part No.     Packaging N
      Winding CHT21340007   Carton Label
      Group 1   Iris
Paint BLUE - LEESON (ENAMEL)   Hazardous Location NONE   Test Card
7.5HP LEESON 1800RPM 213JP DP 3PH MOTOR 199783.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 199783.00
Stock # 199783
