5HP LEESON 3600RPM 182JM DP 3PH WATTSAVER MOTOR 199763.00

Catalog Number:  199763.00 - FREE Ground Shipping In USA
Model Number:  C182T34DK20
Description:  5HP,3600RPM,182JM,DP,3PH,60HZ,JM PUMP
Ship Weight:  73 lbs.

LEESON Three Phase Premium Pump Motors are designed for continuous duty service on close-coupled pumps using NEMA JM mounting provisions. All motors have a rigid mounting base and NEMA JM pump Shaft.

FEATURES:

  • Steel frame
  • Open drip-proof construction
  • Cooling air exhausts at the shaft end for maximum cooling
  • Oversized locked bearing on shaft end limits axial shaft movement
  • High efficiency copper windings with NEMA 1.15 service factors
  • UL and CSA recognized designs
  • Non USA Manufactured, CN
Volts 230 Volts 460 Volts 190/380
F.L. Amps 12.4 F.L. Amps 6.2 F.L. Amps 9/4.5
S. F Amps 14 S. F Amps 7 S. F Amps
RPM 3600 Hertz 60/50
HP 5 Duty CONTINUOUS TYPE TD
KW 3.7 Model # C182T34DK20A
Frame 182JM Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code H
Insul Class F Protection NOT Therm.Prot.
Eff 100% 87.5 Eff 75%   PF 88
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6205
CC Number CC005A CE Yes Bearing PE 6307
Load Type   Inverter Type   Speed Range NONE
Motor Wt.   Enclosure DP Lubrication STANDARD
Nameplate 93405-L-N-ABDFH-B-F Mounting RIGID Rotation REV
Assembly   Shaft Dia.   Ext. Diag. EE7308
Cust Part No   Outline SS620311 Ext. Diag2
Packaging N Outline Dash No   Winding CHT18220006
5HP LEESON 3600RPM 182JM DP 3PH WATTSAVER MOTOR 199763.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 199763.00
Stock # 199763
Price: $409.00
Compare At: $1,384.00
