1.5HP LEESON 1745RPM D90S TEFC IP55 3PH B3 IEC MOTOR 192202.00

Picture is for reference only.

Part Number:

192202.00

Manufacturer:

Leeson Obsolete

Manufacturer Part Number:

C90T17FZ13

192202.00 LEESON 1.5HP IEC Motor meets North American performance standards and premium energy efficiency mandates and have a 1.15 service factor.

Item Discontinued

Click below to view suggested functional replacement.

See Replacement Item

Shipping Details

Weight:

40 lbs

Dimensions:

16 x 20 x 16 inches

HS Code:

8501.52.4000

UPC:

691720246887

Technical Details

Specifications

Brand:	Leeson
Application:	General Purpose
Output HP:	1.5
Output KW:	1.1
Output RPM:	1745
Frame Size IEC:	D90S
Mount IEC:	B3 Foot Mount
Enclosure NEMA:	TEFC
Enclosure IEC:	IP55
Voltage:	230/460

Documentation

Product Information Packet

Additional Information

LEESON AC METRIC MOTORS meet international standards and feature IP55 weatherproof enclosures, 60/50Hz interchangeability (60Hz 230/460 V & 50Hz 200/400V) dual stamped nameplates, CE mark, and F3 conduit box location.

FEATURES:

D flange (B5) and C face (B14) models available. Field conversion kits also offered.
Multi-mount repositionable feet allow for three conduit box positions (F2, F1, F3)
External grounding provision.
CSA: File number LR33543
UL: File number E57948 for motors produced January 2004 and later
