3/4HP LEESON 1130RPM D80D TEFC IP55 3PH B3/B5 IEC MOTOR 192046.00

3/4HP LEESON 1130RPM D80D TEFC IP55 3PH B3/B5 IEC MOTOR 192046.00

B35 ALUMINUM.jpg
Picture is for reference only.

Part Number:

192046.00

Model/Spec Number:

C80T11FZ9

Manufacturer:

Leeson Obsolete
192046.00 LEESON 3/4HP PASSPORT IEC Motor is designed for use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

26 lbs

Dimensions:

12 x 20 x 12 inches

HS Code:

8501.51.4000

UPC:

691720036136

Technical Details

Brand:

Leeson

Application:

General Purpose

Output HP:

3/4

Output KW:

0.55

Output RPM:

1130

Frame Size IEC:

80

Mount IEC:

B35 Foot/Flange

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

IEC Shaft Dia.:

19mm

Product Information Packet
